One flange on bottom with four 3/8 N.C. threads
Two flanges on side with two 3/8″ N.C. threads in each
Two 5/8″” N.C. threaded mounts at 16.00″” centers
Tank is tapered on ends and is shallow in center between mounts

“””

This

This tank has a 2.50 hose connection that sweeps upwards towards the engine, and a 1/2″ NPT flange on the bottom of the tank centered towards the grill side. Note: intended for CAT engine application.

“””

This tank has a 2.50 diameter hose connection 9.50″ from the edge of the tank to the center of the hose connection. This tank is identical to tank #KW 6081

Washer bar for late model Kenworth

This heavy duty bracket has 36 bolt holes, and a pair of steel mounting rings 1.00 deep with 1.87″ holes @ 12.00″” centers. Matches with tank #KW 609.

“””

One flange on bottom with two 3/8 N.C. threaded studs. One 1.00″ O.D. hose connection on driver side.

“””

This frame has 12 bolt holes per flange; two threaded @ 5/16 NC, and various brackets along the back of the frame for mounting a variety of attachments (CAC, condensers, etc…), and there are “ears”” on the gussets for mounting an oil cooler. Note: this frame matches with tank #KW 5911 and tank #KW 6024.

“””
