3 holes threaded 5/16 N.C. (matches #PB 708)

“

This low-flow tank has one 1 1/4 diameter hose connection on a 90^o angle facing up and out to passenger side on approximately 45^oangle. One 1/4″ NPT flange for a drain fitting on the deep section of the tank.

Right side bottom mounting bracket.

This tank has a 1.25 diameter hose connection, and a 3/8″ NPT flange. There is a cut-out in the center of the tank to accommodate a PTO.

“

This tank has a 3.00 hose connection, 11.50″ from the edge of the tank to the center of the hose connection. The connection comes first straight down out of the tank, then bends at 90 degrees to face the engine. This tank is similar to the PB 7195, except that the hose connection does not sweep upward. Note: this tank shares the bolt hole pattern with tank #PB 719 and tank #PB 708.

“

Top flange has 11 bolt holes drilled clearance for 5/16 bolts. Bottom flange has 8 bolt holes drilled clearance for 5/16″ bolts. One angle mount on grille side. Various other holes for brackets, etc.

“

2 Mounting Holes @ 8.62 Centers

Top & Bottom Flanges each have 12 hole, 2 tapped 5/16 NC threaded and 10 drilled clearance for 5/16″ bolts. Engine side of rail is flush with flange with seven 1/4″ NC threaded holes on side.. Two brackets on side – One for CAC and one for mounting pin. NOTE: Frames are not interchangeable.

“
