Top and bottom flanges each have 12 holes, ten drilled clearance for 5/16 bolts and two tapped 5/16″ N.C. One bracket on side of channel near top with two holes drilled clearance for 1/2″ bolts. Angle brackets on each side of channel with 1/4″ N.C. threaded holes. Note: frames are not interchangeable. Order left or right accordingly.

“

Similar to VG 526 except there is less of an overhang; additional bracket welded on side; twelve 3/8 NC threaded nuts on the back of the frame for mounting purposes

“

Top Tank This tank has a 2.50 diameter hose connection, a pair of mounting bosses at each end to attach side frames, four 1/4″ NC threaded blocks on the top, four 1/4″ NC threaded blocks on the grill side, and a 1/4″ NPT flange for an expansion barb. Bottom Tank This tank has a 2.50″ diameter hose connection, a pair of mounting bosses at each end to attach side frames, four 1/4″ NC threaded blocks on the grill side, a 22mm flange for a quick fill line, and two holes @ 11.50″ centers to accommodate an oil cooler.

“

Two flush mounting bolt-on flanges w/ four 1/2 NC bolt holes

matches VG 516 bottom tank flange

One 2.50 O.D. x 3.00″ long hose connection straight out on drivers side(10.75″ in from the end)

One baffle 7/16 off center of tank
