Two bolt-on type flanges with two 7/16 NC threaded holes in each

Two bolt-on type flanges with four 3/8 NC threaded holes in each

Top flange has 13 bolt holes, 7 threaded 5/16 NC and 6 drilled clearance for 5/16″ bolts

Both hose connection 2.50

2.50 Hose Connections that are 9.00″ from the edge of tank. A 1/4″ NPT Flange for drain. A mounting boss at each end to attach side frames. Four 5/16″ NC threaded mounting nuts on the fan and grille side.

“

This tank has three bolt-on type flange connections, a 1/4 NPT and a 3/8″ NPT flange, a 1.25″ hole on top for the solder on cap, and a bolt-on type flange in the built-in baffle. This tank is similar to tank #WS 499, but with slightly different header dimensions and bolt pattern. NOTE: filler neck or caps not available.

“

This tank has two bolt-on type flanges with four 3/8 NC threaded holes, two 1/8″NPT a 3/8″ NPT and a 1/2″ NPT flange, a bolt-on flange with two 3/8″ NC threaded holes on the top of the tank, a 1.25″ hole on top for filler neck, a 1/2″ NPT flange and one bolt-on type flange with two 3/8″ NC threaded holes on the grill side, and a bolt-on type flange with four 5/16″ NC threaded holes in the baffle on the passenger’s side.

“
