Top & bottom flanges have 11 holes, 3 tapped 5/16″ N.C. threads and 8
drilled clearance for 5/16″ bolts. Top flange also has an over hang extending
to 12.50″ with 3 more holes drilled clearance for 5/16″ bolts. Gusset on
over hang has 6 holes, 5 of them drilled 7/16″ dia. and one 3/4″ dia. Various
other holes for brackets & shroud etc. NOTE: Frames are not interchangeable. Order left for driver’s side or right for passenger side or pairs.
Product OEM
| Product-oem | 3MF5490M |
|---|---|
| Make | Western Star |
| Product Type | Radiator Tanks And Parts |
