Ford Charge Air Cooler
Product OEM
| Year-from | 1970 |
|---|---|
| Year-to | 1970 |
| Product-oem | 1E3514, F3HT6K775BB, IE3514 |
| Height | 27.55" |
| Width | 20.03" |
| Depth | 2.62" |
| Inlet | 1.62" |
| Outlet | 1.62" |
| Make | Ford |
