Top and bottom flanges each have 12 holes, 4 tapped 5/16″ N.C. threads
and 8 drilled clearance for 5/16″ bolts. Each side of channel has 4 – 1/4″
N.C. threaded holes. Back of channel has ten 3/8″ N.F. threaded holes.
NOTE: Side frames are interchangeable.
Product OEM
| Product-oem | 3MF5490M |
|---|---|
| Make | Western Star |
| Product Type | Radiator Tanks And Parts |
ADDITIONAL PARTS YOU MAY NEED
Truck
Crane Carrier
- Crane Carrier
- N/A
Various Oshkosh & Advanced Mixers Charge Air Cooler
**Available Re-core Only**
CORE DIMENSIONS
- 19.00"
- 2.00"
- 4.00 "
- 4.00"
Truck
Dodge
- Dodge
- Dodge w/ 5.9L Cummins,Dodge w/ 6.7L Cummins
Dodge Charge Air Cooler
2003 – 2007 5.9L Cummings
2007 – 2008 6.7L Cummings
CORE DIMENSIONS
- 24.68"
- 2.20"
- 3.00"
- 3.00"
Truck
Surge Tanks
International
Truck
Radiators
Mack
- Mack
- MS Model,MIDLINER,CS300
Mack Radiator
Fits 1995 – 2001Mack Midliner
*Available in Solder On Only*
CORE DIMENSIONS
- 22.375"
- 2"
- 4.00"
- 4.00"
Truck
Radiators
International
- International
- 8100 Series
International Radiator
Fits 1990 – 1992 8100 Series
with Cummins Low Flow Engine Cooling System
Must re-use O.E. Frame Brackets
O.E. Frame Must Solder Back On
*Available in Solder on Not Bolt on*
CORE DIMENSIONS
- 26.31"
- 2.25"
- 4.00"
- 4.00" 1.00" Bottom Right 1.25" Bottom Left
Truck
Dodge
- Dodge
- 35,002,500
Dodge Charge Air Cooler
1994 – 2004 Dodge Ram 2500/3500 Available in Powermax
CORE DIMENSIONS
- 15.51"
- 2.25"
- 3.75"
- 3.75"
Truck
Radiators
Freightliner
- Freightliner
- FLD112,FLD106
Freightliner Radiator
FLD 112, 120 (under 425HP)
CAC-FL5A
Condenser-40613
CORE DIMENSIONS
- 27.50"
- 2.25"
- 2.50" Upper Left
- 2.50" Lower Right
Truck
Radiators
Volvo
- Volvo
- VNL,VN
2008-2015 Volvo VN Series
2008-2015 Mack CXU Vision
With Framework
With Oil Cooler
CORE DIMENSIONS
- 35.37"
- 2.00"
- 2.50" Top Left
- 2.50" Bottom Right
Product Comment
Top and bottom flanges each have 12 holes, 4 tapped 5/16″ N.C. threads
and 8 drilled clearance for 5/16″ bolts. Each side of channel has 4 – 1/4″
N.C. threaded holes. Back of channel has ten 3/8″ N.F. threaded holes.
NOTE: Side frames are interchangeable.
